2 Axle 20Ft Rear Tipper Semi Trailer

Product Features :

Start Consulting

Product details

Body/Chassis:

Main chassis: Steel
Tare Weight: 6 tons
Max Payload: 40 tons

Main Beam: Q345B
Height:500mm
Top Flange:12mm
Middle Plate:8mm
Bottom Flange:14mm

Axle:
2 axle*13ton

King-pin
50#/90#

Landing legs:
28 Ton two spe

Brake System
4 double chamber

Suspension
Double air chamber, brake valve, 40L air
tanks

Dimensions:
Total length: 7500mm
Total width 2500mm
Total Height: 3500mm

Tires:
12R22.5*8pcs

Rim:
9.00-22.5*8pcs

Standard Accesspries:
Spare tire carrier*2
LED light

Electricity
Receptacle: 7 ways(7wire harness)and quick change type
Voltage: 24v
